| Specifications
| Camera |
| Image Sensor |
1/2.8” Exmor R CMOS |
| Effective Pixels |
1920(H) x 1080(V), 2 Megapixels |
| RAM/ROM |
1024M/128M |
| Scanning System |
Progressive |
| Minimum Illumination |
Color: 0.005Lux @ F1.6; 0Lux @ F1.6 (IR on) |
| S/N Ratio |
More than 55dB |
| IR Distance |
Distance up to 150m (492ft) |
| IR On/Off Control |
Auto/Manual |
| IR LEDs |
4 |
| Lens |
| Focal Length |
4.8mm~120mm |
| Max. Aperture |
F1.6 ~ F4.4 |
| Angle of View |
H: 59.2° ~ 2.4° |
| Optical Zoom |
25x |
| Focus Control |
Auto/Manual |
| Close Focus Distance |
100mm~ 1000mm |
| PTZ |
| Pan/Tilt Range |
Pan: 0° ~ 360° endless; Tilt: -15° ~ 90°,auto flip 180° |
| Manual Control Speed |
Pan: 0.1° ~300° /s; Tilt: 0.1° ~200° /s |
| Preset Speed |
Pan: 400° /s; Tilt: 300° /s |
| Presets |
300 |
| PTZ Mode |
5 Pattern, 8 Tour, Auto Pan ,Auto Scan |
| Speed Setup |
Human-oriented focal Length/ speed adaptation |
| Power up Action |
Auto restore to previous PTZ and lens status after power failure |
| Idle Motion |
Activate Preset/ Scan/ Tour/ Pattern if there is no command in the specified period |
| Protocol |
DH-SD |
| Intelligence |
| Auto Tracking |
Support |
| IVS (optional) |
Tripwire, Intrusion,Abandoned/Missing, Face Detection |
| Video |
| Compression |
H.265/H.264 / MJPEG |
| Streaming Capability |
3 Streams |
| Resolution |
1080P(1920×1080)/1.3M(1280×960)/720P(1280× 720)/D1(704×576/704×480)/CIF(352×288/352×240) |
| Frame Rate |
Main stream |
1080P/720P/1.3M(1 ~ 50/60fps) |
| Sub stream1 |
D1/CIF(1 ~ 25/30fps) |
| Sub stream2 |
1080P/1.3M/720P/D1/ CIF (1 ~ 25/30fps) |
| Bit Rate Control |
CBR/VBR |
| Bit Rate |
H.265/H.264: 448K ~ 8192Kbps, MJPEG: 5120K ~ 10240Kbps |
| Day/Night |
Auto(ICR) / Color / B/W |
| Backlight Compensation |
BLC / HLC / WDR (120dB) |
| White Balance |
Auto,ATW,Indoor,Outdoor,Manual |
| Gain Control |
Auto / Manual |
| Noise Reduction |
Ultra DNR (2D/3D) |
| Motion Detetion |
Support |
| Region of Interest |
Support |
| Electronic Image Stabilization (EIS) |
Support |
| Defog |
Support |
| Digital Zoom |
16x |
| Flip |
180° |
| Privacy Masking |
Up to 24 areas |
| Audio |
| Compression |
G.711a/G.711Mu/AAC/G.722 / G.726/G.729/MPEG2-L2 |
| Network |
| Ethernet |
RJ-45 (10/100Base-T) |
| Protocol |
IPv4/IPv6,HTTP,HTTPS,SSL,TCP/IP, UDP,UPnP,ICMP,IGMP,SNMP,RTSP,RTP, SMTP, NTP,DHCP, DNS,PPPOE,DDNS,FTP, IP Filter,QoS,Bonjour,802.1x |
| Interoperability |
ONVIF, PSIA, CGI |
| Streaming Method |
Unicast / Multicast |
| Max. User Access |
20 users |
| Edge Storage |
NAS (Network Attached Storage),Local PC for instant recording, 128GB |
| Web Viewer |
IE10/Google/Firefox/Safari... |
| Management Software |
Smart PSS, DSS |
| Smart Phone |
iPhone, iPad, Android, Windows Phone |
| Certifications |
| Certifications |
CE: EN55032/EN55024/EN50130-4 FCC: Part15 subpartB,ANSI C63.4- 2014 UL: UL60950-1+CAN/CSA C22.2,No.60950-1 |
| Interface |
| Video Interface |
N/A |
| Audio Interface |
1/1 |
| RS485 |
N/A |
| Alarm |
2/1 |
| Electrical |
| Power Supply |
AC24V/3A(±10%), PoE+(802.3at) |
| Power Consumption |
13W,23W (IR on) |
| Environmental |
| Operating Conditions |
-40°C ~ 70°C (-40°F ~ +158°F) / Less than 90% RH |
| Ingress Protection |
IP66 |
| Vandal Resistance |
N/A |
| Construction |
| Casing |
Metal |
| Dimensions |
Φ186.0(mm) x 309(mm) |
| Net Weight |
3.5kg(7.72lb) |
| Gross Weight |
6.8kg(14.99lb) |
|
|
|
|
