This type laser cutting and engraving machine has two heads. One for metal and nonmetal cutting and engraving with big power , the other for nonmetal cutting and engraving with small power.

Model

       LXJ1325-H-2 or size customized

Working area (X*Y*Z)

       1300*2500mm or as customized

Table size

       1750*3050*1450mm or as customized

Body structure

       Thicked steel wedding body

rails

       Taiwan hiwin square rails

Z Structure

       Taiwan TBI ball screw

X, Y Resolution

                <0.01mm

Moving Speed

              30000mm/min

Engraving Speed

              20000mm/min

XYZ traveling positioning accuracy

               ±0.01mm

XYZ repositioning accuracy

               ±0.01mm

laser power

 Reci/EFR laser tube (one 90W one 130W)

Power supply

          RECI laser power supply

Voltage

          220v-240V/50hz+-10%

Drive type

           Stepper motors and leadshine drivers

Interface

                    USB

Graphic format

        PLT,DXF,AI,DST,DSB,JPG,BMP,GIF,ETC

Minimum shaping character

            English1×1mm

controller

             RUIDA controller

Laser head

             Metal professionl use laser head

Running Environment

             Temperature: 0℃~45℃

package

             Export wooden box

After packed size

             3.2*2.1*1.78M

G.W

                    1100kgs

1.High speed laser cutting machine adopts the new high efficiency laser tube,the laser beam is

 more stable than the traditional type,and the life time of the laser tube is very long .

2.Compared with the ordinary laser machine,the series adopts more scientific design and high

strength steel frame structure,which increase the fuselage strength more than 40% to prevent the machine from dsitortion during long term work.

3.The humanized and mordem appearance shows  Machinery consistent humanity idea,

and it also makes the operation and maintenace quite easy.

4.Advanced Ruida control system,professional motion control chip,consecutive high speed

curve cutting and the shortest path selection function improve the working efficiency a lot.

This type machine can work on metal and non-metal materials .

1.Metal industry: strainless steel, steel ( the thickness can reach to 3mm )
2.Advertising industry: organic glass ,double color board and other materials.
3.Leather and clothing industry: leather, synthetic leather, leatheroid, cloth, fur and leather, bags, clothes, and other materials.
4.Art & Craft industry: marble, bone, bamboo craft, shell, ivory and so on.

   Jinan Link Manufacture and Trading Co.,Ltd is a modern enterprise integrating reach and development,manufacturing, sale and after sale service, located in Jinan , Shandong Province, China.

  Our main products: large-scale (automatic tool change) cnc routers, cnc laser machine and cnc plasma machine. Also, our machine can be specially customized according to your requirement.

  We offer the best quality machines and timely perfect after-sale service, please contact us.

Q1: When I get this machine, but I don’t know how to use it. What should i do?

We will send you the English manual and CD video for machine using and

maintaining with machine.

If you still have some doubts, we can talk by telephone or skype.

Our engineer can also be sent to your country to install or adjust machine if necessary.

Q2.How about the life-span of the laser tube ?

A: If you operate the machine rightly, it can reach to 1500 or 3000hours.(RECI laser tube can max to 10000hours),It depends on your usage

For example, if it works 8 hours per day, the detailed data as follows:

1, If you set the power at 20%-30% of the total power, the service life is about 1-2years

2, If you set the power at 40-50% of the total power, the service life is about 1 year

3, If you set the power at 70%-80% of the total power, the service life is about 6-8 months

Q3: How can I know the power of the laser tube has been exhausted?

A: you can check the color of the laser beam ,new and strong laser tube is purple when working, otherwise it will be white color.
