Size 10*30mm Saw Edge Aligner One-Word Laser Light D10mm Woodworking Machinery Positioning Infrared 635nm | Инструменты

Size 10*30mm Saw Edge Aligner One-Word Laser Light D10mm Woodworking Machinery Positioning Infrared 635nm | Инструменты

Product Specification [Model Number]:HS-MG-BD1030 [Wavelength]: 635nm [Output power]: Can be adjusted according to customer needs [Supply voltage]: DC 2.8-5.2（V） [Working current]: ≤60mA [Spot mode]: One-word line [Line width]: 0.4 mm - several cm optional [Line length]: Angled lens angle from 5 degrees to 120 degrees optional [Dimensions]: φ10*30mm [Irradiation distance]:Indoor working environment can reach more than 5 meters                                 [Installation height]: 0 meters - 3meters can be used [Feature]: The red line is fine and uniform, and the collimation and stability are very high. [Working temperature]: -20 to +60°C [Storage temperature]: -40 to +85°C [Output Band]: Visible Laser [Operation mode]: continuous laser [Working medium]: semiconductor laser [Structural Features]: High Quality Laser Diode + Metal Case + Quality Lens + Constant Power Circuit Board + Wire [product manual]: ◆ Focus on laser products for decades ◆ Red line width is from 0.4mm to several centimeters ◆ Angled lens angle from 5 degrees to 120 degrees ◆ Pure 635nm wavelength laser light clear and bright ◆ Brand new original imported high quality Taiwan lens can be opened 24 hours a day ◆ Intelligent driver board with imported IC can supply 2.8-5.2V wide range ◆ The inside is filled with heat-dissipating silicone and AB glue. It can not only fully dissipate heat but also resist shock and drop. ◆ The outer shell is aviation aluminum plated insulating paint. It can not only fully dissipate heat but also shock and drop resistance and static electricity. ◆ High temperature resistant corrosion resistant DC plug wire Suitable for all-weather and all-around use
