Характеристики
VICHY VC8145 DMM Digital Bench Top Multimeter Temperature Meter Tester PC Analog 80 000 counts Bar Graph w/ 23 segments | Инструменты
История изменения цены
*Текущая стоимость 10 578,85 уже могла изменится. Что бы узнать актуальную цену и проверить наличие товара, нажмите "Добавить в корзину"
| Месяц | Минимальная цена | Макс. стоимость | Цена |
|---|---|---|---|
| Mar-18-2026 | 12588.69 руб. | 13217.32 руб. | 12902.5 руб. |
| Feb-18-2026 | 12482.22 руб. | 13106.29 руб. | 12794 руб. |
| Jan-18-2026 | 10472.20 руб. | 10996.31 руб. | 10734 руб. |
| Dec-18-2025 | 12270.39 руб. | 12884.10 руб. | 12577 руб. |
| Nov-18-2025 | 10684.99 руб. | 11218.15 руб. | 10951 руб. |
| Oct-18-2025 | 12059.10 руб. | 12662.46 руб. | 12360.5 руб. |
| Sep-18-2025 | 11953.39 руб. | 12551.17 руб. | 12252 руб. |
| Aug-18-2025 | 11847.17 руб. | 12439.23 руб. | 12143 руб. |
| Jul-18-2025 | 11742.16 руб. | 12329.37 руб. | 12035.5 руб. |
Описание товара
Product Description
The Professional Bench Top Multimeter is a unique multi-functional device that has 4 7/8 digits Dual Display with 80,000 counts and Analog Bar Graph with 23 segments. This precision LCR meter is a cost-effective solution for component and material measurement.Measure speed is about 3 per second and with more than 50 measuring functions including DC/AC Voltage, DC/AC Currents, Resistance (Ω), Capacitance, Frequency (Hz), Rotational Speed, Square Waveform, Temperature (C/F), Duty Cycle, Diode and Continuity Check.
Moreover, you can connect it to your computer through RS-232 Cable. The meter can provide functions including analog bar and unit symbol display, data holding, relative value measuring and maximal/minimal value measuring.
This multimeter is most suitable for use on production lines, laboratories, factories, radio-technology, R & D, maintenance and repairing work.The meter can provide functions including analog bar and unit symbol display, data holding, relative value measuring and maximal/minimal value measuring. Features:
- High contrast and Wide visual angle LCD display with backlight
- Dual Display:
- Main Display: 80000
- Secondary Display: 80000
- Analog Bar Graph: 23 segments, update 40 time/sec
- More than 50 measuring functions including DC/AC Voltage, DC/AC Currents, Resistance (Ω), Capacitance, Frequency (Hz), Temperature (°C/°F), Duty Cycle, Diode & Continuity Check
- Single Analyzed:
- (AC+DC) measuring synchronous
- (AC+Hz) measuring synchronous
- (DC+dBm) measuring synchronous
- (dBm+Hz) measuring synchronous
- (Hz+Duty) measuring synchronous
- (°C+°F) displaying synchronous
- Frequency measurement : 0.5Hz -1000.000000MHz
- Basic DC Accuracy : 0.05 %
- mV Impedance : >1000MΩ
- 16 Frequency points, 1% to 99% duty selectable square wave output
- Analyzing component of current or voltage signal
- Resistance Measuring : 0.1Ω to 80MΩ,10MΩ to 8000MΩ
- Capacitance Measuring : 10nF to 100µF
- Temperature Measuring : -50°C to 1372°C, -58°F to 2502°F
- dBm 20 types of reference impedance
- Auto data hold/ peak hold
- Relative measuring : REL, Relative percent : REL%
- 36 hours dynamic recording : MAX / MIN / AVG / MAX-MIN
- Communication : 9-pin isolated optical RS232 cable
- Measure speed is about 3 per second
- Timer for measurement
- Safety/Compliance : IEC 61010 CAT II 1000V ; CAT III 600V
- Auto power off
- 0.1 ~ 99.9% pulse duty cycle measuring
- Set upper and lower limit area measuring
- Photoelectricity insulation RS-232 computer interface
- Timing measuring function
- AC measuring adopt High accuracy RMS, Widely measuring and AC+DC function, can measure the accuracy virtual value of AC by any wave
- Maximum voltage between any terminal and earth ground: 1000V RMS
- Continuity Beeper: 3kHz Approx.
- Operating Temperature: 0°C to +50°C
- Storage Temperature : -20°C to +60°C
- Operating Altitude: under 2000m
- Storage Altitude : under 10,000m
- Relative Humidity : ≤75% at 0°C to +40°C
- Electromagnetic Compatibility : in a RF field or 1 V/m on all ranges and function except Capacitance
- Total Accuracy : specified +5% of range Capacitance not specified in RF fields performance above 1 V/m is not specified
- PC Interface : RS-232
- Compatible with Windows 2000 & XP only
- AC Power : 110~220 V (US / EU / AU / UK Power adapter plug)
- Size : approx. 242 x 212 x 98 mm
- Weight : approx.1388g (accessories not included)
| Range | Resolution | Accuracy |
| 80mV | 1μV | ±(0.3% rdg + 10) |
| 800mV | 10μV | ±(0.05% rdg + 5) |
| 8V | 0.1mV | |
| 80V | 1mV | |
| 800V | 10mV | |
| 1000V | 0.1V | ±(0.08% rdg + 10) |
| Range | Resolution | Accuracy |
| 80mV | 1μV | ±(0.3% rdg + 10) |
| 800mV | 10μV | ±(0.05% rdg + 5) |
| 8V | 0.1mV | |
| 80V | 1mV | |
| 800V | 10mV | |
| 1000V | 0.1V | ±(0.08% rdg + 10) |
| Range | Resolution | Accuracy | Notes |
| 80mA | 1μA | ±(0.2%rdg + 10) | Fuses:F 750mA/250V F 13A/250V Voltage drop: ≤800mV Max. Input Current: 20A (up to 15 seconds) |
| 800mA | 10μA | ||
| 8A | 0.1mA | ±(0.5%rdg + 10) | |
| 20A | 1mA |
| Range | Resolution | Accuracy | Notes |
| 80mA | 1μA | 50Hz ~ 5kHz ±(0.8%rdg + 20) | Fuses:F 750mA/250V F 13A/250V Voltage drop: ≤800mV Max. Input Current: 20A (up to 15 seconds) |
| 800mA | 10μA | ||
| 8A | 0.1mA | 50Hz ~ 500Hz ±(1.0%rdg + 20) | |
| 20A | 1mA |
dBm (Power Ration in decibels)
| Range | Resolution | Accuracy |
| -80.00dBm ~ +80.00dBm | 0.01 dBm | ±1.0% reading |
Resistance (Ω)
| Range | Resolution | Accuracy |
| 800Ω | 0.01Ω | ±(0.3% rdg + 10) |
| 8kΩ | 0.1Ω | ±(0.3% rdg + 5) |
| 80kΩ | 1Ω | |
| 800kΩ | 10Ω | |
| 8MΩ | 100Ω | |
| 80MΩ | 1kΩ | 0 ~ 40MΩ: ±(2.5% rdg + 10) 40 ~ 80 MΩ: ±(3.5% rdg + 10) |
Frequency (Hz)
| Range | Resolution | Accuracy | Note |
| 999.99Hz | 0.01Hz | ±(0.05% rdg+ 5) | Overload Protection: 250V RMS Sensitivity: 0.7V RMS |
| 9.9999kHz | 0.1Hz | ||
| 99.999Hz | 1Hz | ||
| 999.99Hz | 10Hz | ||
| 8.0000MHz | 100Hz | ||
| 10.0MHz | 1kHz | ±(0.1% rdg+ 5) | Plus Adapter |
| 100.0MHz | 10kHz | ||
| 1000.0MHz | 100kHz |
Capacitance
| Range | Resolution | Accuracy |
| 1nF | 1pF | ±(5.0% rdg+ 50) |
| 10nF | 10pF | ±(2.5% rdg+ 50) |
| 100nF | 100pF | |
| 1 μF | 1nF | |
| 10μF | 10nF | |
| 100μF | 100nF |
Diode
| Range | Resolution | Accuracy |
| 3.0000 V | 0.0001 V | ±(3.0% rdg+ 5) |
Square Wave Output
| Square Wave Output | Description |
| Voltage Amplitude | Approx. 3V |
| Frequency | 0.5 ~ 5000 Hz |
| Duty Cycle | 1 ~ 99% |
Temperature
| Range | Resolution | Accuracy |
| -50 ~ 1300 °C | 0.1 °C | ± (1.5% rdg+ 10) |
| -58 ~ 2372 °F | 0.1 °F |
Set Includes:- 1 x Digital Bench Top Multimeter
- 1 x Pair of Test Leads
- 1 x Type K Thermocouple
- 1 x RS-232 Software CD
- 1 x 9-pin Cable Adapter
- 1 x AC Power Cord (available in US / EU / AU / UK Power Plug)
- English Instruction Manual
- Standard Packaging Box
