Описание товара
4 axis CNC controller USB Control MPG drilling machine cnc control Stand Alone multi functional stepper servo motor
Basic Functions
Control number of axes 4 axes
Number of linkage axes Full linkage
Analog spindle 2
Spindle magnification 50% to 120%
Minimum instruction unit 0.001 mm
Maximum command value ± 99999999 × minimum instruction unit
Fastest feed rate 12000 mm / min
Rapid feed override F0, 25%, 50%, 100%
Cutting feed rate 12000 mm / min
Feed rate override 0% to 150%
Electronic gear ratio 1 ~ 65535: 1 ~ 65535
Automatic acceleration and deceleration Yes
Positioning G00 (linear interpolation)
Interpolation Straight line (G01), arc (G02 / G03 / G05)
Return to reference point Automatic return reference point (G28)
LCD 3.5 inch TFT LCD screen with resolution 480X320
MDI software button Five
Single feed X1, x10, x100
Communication Interface U disk interface
External hand wheel interface Yes
I / O interface 24/24 (expandable to 96/96)
Pause (s) Yes
Quasi-stop state Yes
Quasi-stop Yes
Storage trip check Yes
MDI operation Yes, support multi-segment operation
Reset Yes
Check off switch Yes
Single run Yes
Program protection switch Yes
Self-diagnostic function Yes
Emergency stop Yes
power supply DC24V
Coordinate System G53, G92, G54-G59, G52
Automatic coordinate system setting Yes
Decimal point input Yes
Auxiliary function M code custom defined, manual / MDI / automatic mode control spindle forward, reverse, stop; control coolant start and stop.
Spindle Function Double Analog Spindle
Tapping Yes
Tool Function
Tool Function 2Pcenter and 3Pcenter tool setting
Tool Offset Memory -9999.999-9999.999, number 99
Tool Offset Length offset
Edit function
Parameter, diagnostic bit-wise input, program editing, MDI multi-block execution
Storage 128M
Number of stored programs 200
The display of the program name Chinese, English, numbers, combinations
Look up for program line Yes
Skip optional program lines Yes
Program switch Yes
Display
display Chinese/ English
Processing time, number of parts display Yes
Spindle speed, M / S command Yes
Variables Yes
Package includes
One controller
Four packs of connectors
We provide pdf English manual, please leave your email after purchase(Manual includes operation, G codes, M codes and Variables)
Note: We are the only licensed seller from the factory on aliexpress for selling this controller, you will be fully protected of after sale rights, orders from other store will not enjoy the after sale services from us.
We provide full technical support, welcome to contact us if you have questions. We will give help documents from time to time, please leave your email after the order.
We provide one and half year ganrantee since the day you receive the controller, man made damage not included.
If buyer ordered the wrong product, please contact us within 10 days after you receive. Buyer can return it back to us. Buyer will pay for the fee shipping back.
If the product is defected or damaged during transportation, please contact us after you receive. Buyer can return it back to us. We will pay for the fee shipping back. Shipping fee will be paid to buyer's paypal address. Then we give a new product or make refund. In case the buyer has no paypal account, we give discount of the same amount equals to the shipping fee for buyer's next order, no matter what the buyer want to buy. We will make sure the buyer is fully compensated.
