Product Description

• The USB3.0 IMX178 Color camera has high sensitivity, high frame rates, amp glow and low noise for Moon, Sun, Planets as well as Galaxies, Cluster and Nebulae imaging.
• A built-in ST4 auto guider port for the easy connection of the auto guider.
• Free Software supports video preview, video record, video processing, image capture and process, dark field correction and raw data output.
• Native/ASCOM/WDM driver for easy connection with 3rd party astrophotography software such as PHD Guiding, Nebulosity, , SharpCap, MetaGuide, FireCapture, and Astroart.

Camera Specifications:

• Sensor: 6.3MP SONY IMX178 CMOS sensor（color）
• Sensor Size: 1/1.8”(7.37x4.91)
• Pixel(μm): 2.4 x2.4
• ST4 auto guider port: Yes
• Exposure: 0.244ms~1000s
• G Responsivity: 425mv with 1/30s
• Dark Signal: 0.15mv with 1/30s
• FPS/Resolution: 59@3040 x 2048 58@1520 x 1024
• Binning: 1x1,2x2
• ROI: Supported
• Bit Depth: 8bit/14bit
• Protect window: IR-cut Filter
• Out put: USB3.0
• Support System: Windows XP/Vista/7/8/10, Mac, Linux
• Mounting Sizes: C-mount
If you want to get fast frame rate pls reduce the exposure time.
If you want to get more exposure time pls use trigger mode.

Software Features:

• Free Software Toupsky supports video preview, video record, video processing, image capture and process, dark field correction and raw data output.
• Various professional functions : Video broadcast; Time lapse capture; Video record; Video stream grid; Image stitch; Video scale bar, date and etc.
• Control and adjust image by denoise, sharpen, color toning deinterlace, all kinds of filtering algorithm and mathematical morphology algorithm, range, binary, pseudo color, surface plot and line profile etal.
• Image stacking adopts advanced image matching technology. With the recorded video, regardless of shifting, rotation, scaling, the high fidelity image can be stacked to decrease the image noise.
• Native/ASCOM/WDM driver for easy connection with 3rd party astrophotography software such as PHD Guiding, Nebulosity, , SharpCap, MetaGuide, FireCapture, and Astroart.
• Unlimited language support, currently available in Simplified Chinese, Traditional Chinese, English, Russian, German, French, Polish and Turkish.

Example images

Contents:

Standard Packing List:
B: One Box
C: One USB3.0 G3M Camera
D: One USB3.0 Cable
E: One guide cable
F:One 1.25 inch nosepiece
G: One CD with Software

Optional Accessory:
H: One CS-mount ring

Customer Service:

• One year Warranty. • Before and after the purchase - we from Imageview Store will find the right solution for you!
• We do not leave you alone after the purchase and value customer-oriented service.
• If you have any questions or problems with one of our products, pls feel free to contact us and we will be pleased to help you.
