Dso Fnirsi Pro Handheld Mini Portable Digital Oscilloscope 5M Bandwidth 20Msps Sampling Rate | Инструменты
История изменения цены
*Текущая стоимость уже могла изменится. Что бы узнать актуальную цену и проверить наличие товара, нажмите "Добавить в корзину"
| Месяц | Минимальная цена | Макс. стоимость | Цена |
|---|---|---|---|
| Sep-18-2025 | 0.12 руб. | 0.61 руб. | 0 руб. |
| Aug-18-2025 | 0.72 руб. | 0.72 руб. | 0 руб. |
| Jul-18-2025 | 0.50 руб. | 0.4 руб. | 0 руб. |
| Jun-18-2025 | 0.48 руб. | 0.12 руб. | 0 руб. |
| May-18-2025 | 0.35 руб. | 0.41 руб. | 0 руб. |
| Apr-18-2025 | 0.97 руб. | 0.8 руб. | 0 руб. |
| Mar-18-2025 | 0.52 руб. | 0.9 руб. | 0 руб. |
| Feb-18-2025 | 0.49 руб. | 0.85 руб. | 0 руб. |
| Jan-18-2025 | 0.45 руб. | 0.45 руб. | 0 руб. |
Описание товара
Equipped with high efficiency one button AUTO, the measured waveform can be displayed without complicated adjustment. Display the High Definition LCD screen equipped with 2.4 inch 320*240 resolution. Extremely convenient and fast waveform storage function, built-in 16MB storage space, the maximum storage of 500 waveform pictures.
Powerful waveform file manager, support thumbnail browsing, viewing, details view, flip, delete and other functions. Built in 1200mAh rechargeable lithium battery can be continuously charged for 3 hours at one time. Day mode and night mode can be changed according to their own preferences.
1:Memory compression technology, waveform refresh screen does not flicker. 2:Afterglow display technology. 3:2.4 inch color display screen. 4:5MHz analog bandwidth @ 20MS/s sampling rate. 5:Fast waveform storage. 6:Built-in 16M storage space, the maximum storage of 500 waveform pictures. 7:Powerful waveform file manager, support thumbnail browsing, viewing, details view, flip, delete and other functions
8:High measurement voltage range, 1X can measure 0 ~ 40 V, 10X can measure 40 ~ 800V. 9:Up to 11 parameters .
color: White
Material: ABS+ electronic components
easurement:VPP,Vmax,Vmin,Vavg,Vrms,Frequent,Duty+,Duty-,Time+,Time-,Time. 10:At any time, the waveform display (pause function) is frozen
11:Equipped with high efficiency one button AUTO. 12:Complete triggering function (single, normal, automatic) 13:Built in 1200mAh rechargeable lithium battery can be continuously charged for 3 hours at one time. 14:Day mode and night mode. 15:Ultra small volume, easy to carry
1:Analog band width: 5MHz
2:Maximum real time sampling rate: 20MS/s
3:Vertical sensitivity: 50 mV/div ~ 200 V/div
4:Horizontal time base range: 50S/div ~ 250nS/div
5:Maximum input voltage: 40 V (1X probe), 800 V (10X probe)
6:Storage depth: 40KB
7:Input resistance: 1M
8:ADC precision: 8bits
9:Coupling mode: AC/DC
10:Trigger mode: Single, Normal, Automatic
11:Trigger edge: Ascending/descending edge
12:External trigger voltage 0 – 40 V
13:Display: 2.4 inch @ 320 * 240
14:Power supply: 1200 mAh lithium battery
15:Size: 107 x 70 x 24mm
16:Weight: 150g
Package includes:
1 x DSO FNIRSI PRO oscilloscope host1 x Crocodile clip probe
1 x Micro-USB data line
1 x User manual (English)
Only the above package content, other products are not included.
Note: Light shooting and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is +/- 1-3cm.
|
